Regency® Pro-Series F5200 Wood Stove

Regency Fireplace Products

Extra Large Hybrid Catalytic Wood Stove

The F5200 wood stove lets you load an impressive 90 pounds of fuel. Its clean, classic design provides the perfect backdrop to the wide view cast door giving you a large fire view that will take your breath away!

The Regency Pro-Series F5200 extra-large hybrid wood burning freestanding stove is one of the original Regency stoves that feature Eco-Boost triple burn technology. When the included thermometer enters the "Active" range, use the bypass control to engage the catalyst; and watch your fire burn longer and more consistent, while still being environmentally friendly.

Opening the door a full 170 degrees, lets you load up to 90 lbs. of 22" logs (front to back & side to side) at one time and the discreet ash lip will help to keep the floor in front of your new stove clean. You will be able to fit this unit anywhere in your home, using the rear heat deflector (included) to give you the closest clearances in the industry.

F5200 Wood Stove Key Features:

  • Load wood front to back or side to side
  • Large fire viewing area, with heat radiating ceramic glass
  • Heavy duty cast hinges that will never bend or break
  • Solid forged steel adjustable cam lock ensures a tight door seal over time
  • Front mounted air adjustment & side mounted catalytic bypass
  • Easy-to-read catalytic thermometer helps your stove reach maximum burn times & efficiency
  • High performance brick-lined firebox reflects heat
  • Non-obtrusive air wash curtain keeps glass clean
  • Welded ash lip will never bend or break
  • Rear heat deflector allowing for closer clearances
  • Mobile home and alcove approved
  • 170° opening door for easy loading
  • Heavy duty 3/16 in. steel firebox
  • Triple-burn technology creates longer and more complete burns
  • Backed by the industry’s most comprehensive Limited Lifetime Warranty
  • 10-year, 100% coverage on original catalyst

Key Features & Technologies

The following accessories are available for this product. You can also design your own fireplace with the Fireplace Design Center.

Hover for larger images and details.

Blower

  • 2-speed
    2-speed
    2-speed
    2-speed



Airmate

  • Airmate
    Airmate
    Airmate
    Airmate



Ashdrawer

  • Ashdrawer
    Ashdrawer
    Ashdrawer
    Ashdrawer



The following specifications and literature apply to this product. You can also design your own fireplace with the Fireplace Design Center.

Energy Specifications
Optimum Efficiency 86%
Maximum BTU 80,000
General Specifications
Product Size Extra Large
Log Size 22"
Burn Time up to 30 hrs
Firebox Capacity 4.4 cu. ft.
Emissions (gms/hr) 0.9
View Area 213 sq. in.
Room Size Large
Vent Type Double Wall Pipe
Vent Size (Air Intake) N/A
Vent Size (Exhaust) 8"
Unit Dimensions
Width (front)
Height
Depth
Dimension Notes: Height with Pedestal
